The following are the selections for the parameter.
Selection number
Selection name
0
Disabled
1
Enabled
P 9.4.5 Invert Direction Channel 2
Description: Select if signal on channel 2 shall be inverted. For dual channel encoders, this parameter only affects the incremental
part, to be used if the A and B signal inputs are switched.
Default Value : 0 [Disabled]
Parameter Type: Selection
Parameter Number: 4093
Unit: -
Data Type: BOOL
Access Type: Read/Write
The following are the selections for the parameter.
Selection number
Selection name
0
Disabled
1
Enabled
5.6.3 Incremental Settings (Menu Index 9.5)
P 9.5.1 Resolution Channel 1
Description: Set the resolution of the incremental encoder connected to channel 1.
Default Value : 1024
Parameter Type: Range (0 — 65535)
Parameter Number: 4008
Unit: -
Data Type: UINT
Access Type: Read/Write
P 9.5.2 Resolution Channel 2
Description: Set the resolution of the incremental encoder connected to channel 2.
Default Value : 1024
Parameter Type: Range (0 — 65535)
Parameter Number: 4009
Unit: -
Data Type: UINT
Access Type: Read/Write
5.6.4 SSI/EnDat/BiSS/HIPERFACE Settings (Menu Index 9.6)
P 9.6.1 Singleturn Resolution
Description: Set the number of bits used for 1 revolution.
Default Value : 13
Parameter Type: Range (1 — 32)
Parameter Number: 4010
Unit: -
Data Type: UINT
Access Type: Read/Write
P 9.6.2 Multiturn Resolution
Description: Set the number of bits used for counting the revolutions.
Default Value : 12
Parameter Type: Range (0 — 32)
Parameter Number: 4011
Unit: -
Data Type: UINT
Access Type: Read/Write
P 9.6.3 EnDat Clock Rate
Description: Select the clock rate used for EnDat.
Default Value : 13 [1 MHz]
Parameter Type: Selection
Parameter Number: 4036
Unit: -
Data Type: UINT
Access Type: Read/Write
The following are the selections for the parameter.
AQ390830267692en-000601 / 136R027340 | Danfoss A/S © 2023.06
Encoder/Resolver Installation and
Configuration
Functional Extension Options
Operating Guide
