Selection number
Selection name
0
8.33 MHz
6
4.16 MHz
12
2.08 MHz
13
1 MHz
14
0.2 MHz
15
0.1 MHz
P 9.6.4 SSI Data Format
Description: Select the SSI data coding according to the specifications of the connected SSI encoder.
Default Value : 1 [Gray]
Parameter Type: Selection
Parameter Number: 4034
Unit: -
Data Type: BOOL
Access Type: Read/Write
The following are the selections for the parameter.
Selection number
Selection name
0
Binary
1
Gray
P 9.6.5 BiSS/SSI Clock Rate
Description: Select the clock rate used for SSI or BiSS.
Default Value : 18 [833 kHz]
Parameter Type: Selection
Parameter Number: 4037
Unit: -
Data Type: UINT
Access Type: Read/Write
The following are the selections for the parameter.
Selection number
Selection name
2
8.33 MHz
3
6.25 MHz
4
5.00 MHz
5
4.16 MHz
6
3.57 MHz
7
3.13 MHz
8
2.78 MHz
9
2.50 MHz
10
2.27 MHz
11
2.08 MHz
12
1.92 MHz
13
1.79 MHz
14
1.67 MHz
AQ390830267692en-000601 / 136R0273 | 41Danfoss A/S © 2023.06
Encoder/Resolver Installation and
Configuration
Functional Extension Options
Operating Guide
