Danfoss ICAD 600 Instruction

5 DKRCI.PI.HV0.E6.02 / 520H3832 © Danfoss A/S (AC-SMC/MWA), 08-2011
Parameter list - Valid from: (i58:9, i59:18)) and onwards
Description ICAD
parameter
Min Max Factory
Setting
Stored Unit Pass
word
Comments
OD (Opening degree) - 0 100 % - ICM valve Opening Degree is displayed during normal operation.
Running display value (see ¡01, ¡05).
Main Switch ¡01 1 2 1

- No Internal main switch
1: Normal operation
2: Manual operation. Valve Opening Degree will be ashing. With the down
arrow and the up arrow push buttons the OD can be entered manually.
Mode ¡02 1 2 1

- No Operation mode
1: Modulating – ICM positioning according to Analog Input (see ¡03)
2: ON/OFF - operating the ICM valve like an ON/OFF solenoid valve
controlled via Digital Input. See also ¡09.
3: Neutralzone / 3 point control. Increase/Decrease Opening Degree by
Digital Input. See g. 9
AI signal ¡03 1 4 2

- No Type of AI signal from external controller
1: 0-20 mA
2: 4-20 mA
3: 0-10 V
4: 2-10 V
Speed
In Modulating Mode
Opening/closing speed
In ON/OFF Mode
Opening speed
¡04 1 100 50/ 100

- No Speed can be decreased. Max. speed is 100 % - Not active in manual operation (¡01 =
2)
If ¡26= 1 - 3 then factory setting =100
If ¡26= 4 - 9 then factory setting =50
If ICM is opening and (¡04 < = 33) or ICM is closing and (¡14 < = 33)
=> Low is displayed.
If ICM is opening and (33 < If ¡04 < = 66) or ICM is closing and (33 < If ¡14 < = 66)
=> Med is displayed.
If ICM is opening and (¡04 > = 67) or ICM is closing and (¡14 > = 67)
=> High is displayed"
Automatic calibration ¡05 0 2 0 - No Not active before ¡26 has been operated.
Always auto reset to 0.
CA will ash in the display during calibration,
if Enter push button has been activated for two seconds
0: No Calibration
1: Normal forced calibration - CA ashing slowly
2: Extended calibration – CA ashing rapidly"
AO signal ¡06 0 2 2

- No Type of A0 signal for ICV valve position
0: No signal
1: 0-20 mA
2: 4-20 mA
Failsafe ¡07 1 4 1

- No Dene condition at power cut and fail safe supply is installed.
1: Close valve
2: Open Valve
3: Maintain valve position
4: Go to OD given by ¡12"
Fail safe supply ¡08 0 1 0

Yes Fail safe supply connected and enable of A4 alarm:
0: No
1: Yes
DI function ¡09 1 2 1

No Dene function when DI is ON (short circuited DI terminals) when ¡02 = 2
1: Open ICM valve (DI = OFF = > Close ICM valve)
2: Close ICM valve (DI = OFF = > Open ICM valve)
Password ¡10 0 199 0 - - Enter number to access password protected parameters: ¡26
Password = 11
Old Alarms ¡11 A1 A99 - - No Old alarms will be listed with the latest shown rst. Alarm list can be reset by means
of activating down arrow and up arrow at the same time for 2 seconds.
OD at power cut. ¡12 0 100 50

No Only active if ¡07 = 4
If fail safe supply is connected and power cut occurs, the ICM will go to the specied OD.
Inverse operation ¡13 0 1 0

No When ¡02 = 1
0: Increasing Analog Input signal => Increasing ICM Opening Degree
1: Increasing Analog Input signal => Decreasing ICM Opening Degree
When ¡02 = 3
0: DI1 = ON, DI2 = OFF => Increasing ICM Opening Degree.
DI1 = OFF, DI2 = ON => Decreasing ICM Opening Degree
DI1 = DI2 = OFF => ICAD/ICM maintain current position
DI1 = DI2 = ON => ICAD/ICM maintain current position
1: DI1 = ON, DI2 = OFF => Decreasing ICM Opening Degree
DI1 = OFF, DI2 = ON => Increasing ICM Opening Degree
DI1 = DI2 = OFF => ICAD/ICM maintain current position
DI1 = DI2 = ON => ICAD/ICM maintain current position
In ON/OFF Mode
Closing speed
¡14 0 100 50/ 100

- No See ¡04.
If ¡26= 1 - 3 then factory settin qg = 100
If ¡26= 4 - 9 then factory setting = 50
Manual set point ¡15 0 100 0 No When ¡01= 2, ¡15 determine the start up value.
Encoder operation ¡16 0 1 0/1

Yes NB: Password protected. Password = 7
If ¡26 = 1 - 3 then factory setting = 0
If ¡26 = 4 - 6 then factory setting = 0 (1 if ICAD1200)
If ¡26 = 7 - 9 then factory setting = 1
0: Encoder disabled. Means ICAD operation as ICAD 600/900
1: Encoder enabled
ICM conguration ¡26 0 9 0

Yes NB: Password protected. Password = 11
0: No valve selected. Alarm A1 will become active.
1: ICM 20 with ICAD 600
2: ICM 25 with ICAD 600
3: ICM 32 with ICAD 600
4: ICM 40 with ICAD 900/1200
5: ICM 50 with ICAD 900/1200
6: ICM 65 with ICAD 900/1200
7: ICM 100 with ICAD 1200
8: ICM 125 with ICAD 1200
9: ICM 150 with ICAD 1200
