Service
Description
ICAD
parameter
Min Max
Factory
Setting
Stored Unit Password Comments
OD % ¡50 0 100 - % - ICM valve Opening Degree / CVE pressure setting
AI [mA] ¡51 0 100 - mA - AI signal
AI [V] ¡52 0 100 - V - AI signal
AO [mA] ¡53 0 100 - mA - A0 signal
DI ¡54 0 1 - - -
DI signals. Depending of ¡02
If ¡02 = 2, one digits are shown. See fig. 8
0 : DI1 = OFF
1 : DI1 = ON
If ¡02 = 3, two digits are shown. See fig. 9
00 : DI1 = OFF, DI2 = OFF
10 : DI1 = ON, DI2 = OFF
01 : DI1 = OFF, DI2 = ON
11 : DI1 = ON, DI2 = ON
DO Close ¡55 0 1 - - - DO Closed status. ON when OD < 3 %
DO Open ¡56 0 1 - - - DO Open status. ON when OD > 97 %
DO Alarm ¡57 0 1 - - - DO alarm status. ON when a Alarm is detected
Display mP SW ver. ¡58 0 100 - - - Software version for display microprocessor
Motor mP SW ver. ¡59 0 100 - - - Software version for motor microprocessor
Reset to factory setting:
1. Remove the power supply.
2. Activate down arrow and up arrow push buttons at the same time.
3. Connect the power supply.
4. Release down arrow and up arrow push buttons.
5. When the display on ICAD (fig. 2) is alternating between showing: CA and A1 the
factory resetting is complete.
