Pinout
Pin location
1 2
P003480
Pinout
Pin Description
1 PWM signal/voltage input
2 Ground
Pin compatibility
PLUS+1
®
module pin type
Pin Function
1, 2 PWMOUT/DOUT/PVG Power supply
1, 2 PWMOUT/DOUT/PVGOUT
1, 2 Power ground -
Input/output matrix
EDC/C1 and C2 location
P003 191
Electrical Installation
M46 Pumps HC EDC
Electrical installation
8 L1427804 • Rev AB • September 2015
