Danfoss PFM 5001 - Calculating Pressure Loss on Valve

Calculation of
the pressure
loss on the
valve for
required flow
1. Click on Calculations button in the main menu. 2. Select valve and enter the
current presetting in the
branch. Click on Calculate
pressure loss button.
3. Enter the required flow for
the branch.
4. Answer will appear in the
Results window.
HEC 31
