Power
Module supply voltage/maximum current ratings
PLUS+1
®
modules are designed to operate with a nominal 9 to 36 Vdc power supply.
The modules will survive with full functionality if the supply voltage remains below 36 Vdc.
Specifications
Description Units Minimum Maximum Comment
Allowed voltage at pin V 0 36
Allowed module current A 0 120
C
Caution
PCB damage may occur.
To prevent damage to the module all module power supply + pins must be connected to the vehicle
power supply to support advertised module maximum output current capacity. DO NOT use module
power supply + pins to supply power to other modules on a machine.
Sensor power supply ratings
PLUS+1
®
modules that support sensor inputs are provided with dedicated, software adjustable, regulated
sensor power supply and ground pins. Refer to individual product data sheets for sensor power supply
current ratings.
The sensor power is nominally 5 Vdc, unless otherwise noted on the product data sheet.
General
Description Comment
Short circuit to ground
Output is not damaged and fault is detected.
Short circuit to battery +
Output is not damaged and fault is detected.
Specifications (all modules except MC050-055/05B)
Description Units Minimum Maximum Comment
Output short circuit voltage V 36
Output voltage V 4.88 5.12
Output current mA Refer to individual data sheets for
sensor power supply ratings.
Output Load Capacitance µF 10
Hold up time after power loss ms 5 15
MC0XX-1XX controllers feature two additional levels of regulated power: 1.6 Vdc and 3.3 Vdc. The PLUS
+1
®
GUIDE application developer can detect open and short digital inputs, when these power supplies
are used in conjunction with DIN/AIN inputs.
Specifications (MC50-155/15B)
Description Units Minimum Maximum Comment
Output short circuit voltage V 36
Output voltage, sensors V 4.56 5.10 Sensor power supply drops below
minimum if controller power supply
is less than 9 Vdc.
Technical Information
PLUS+1® MC0XX-1XX Controller Family
Product ratings
20 |
©
Danfoss | April 2018 L1321895 | BC00000227en-US0401
