Connectors
PLUS+1
®
modules use DEUTSCH connectors. Danfoss assembles mating connector kits, referred to as a
bag assembly.
Mating connector bag assembly ordering information is found in module product data sheets.
DEUTSCH mating connector part information
Description 12 pin module 24 pin module 50 pin module
Crimp tool HDT48-00 (solid contacts)
(20 to 24 AWG)
HDT48-00(solid contacts)
(20 to 24 AWG)
HDT48-00 (solid contacts)
(20 to 24 AWG)
DTT20-00 (stamped
contacts)
(16 to 20 AWG)
DTT20-00 (stamped
contacts)
(16 to 20 AWG)
DTT20-00 (stamped
contacts)
(16 to 20 AWG)
Contacts Solid: 0462-201-2031
(20 to 24 AWG)
Solid: 0462-201-2031
(20 to 24 AWG)
Solid: 0462-201-2031
(20 to 24 AWG)
Stamped: 1062-20-0144
(16 to 20 AWG)
Stamped: 1062-20-0144
(16 to 20 AWG)
Stamped: 1062-20-0144
(16 to 20 AWG)
Connector plug Gray A-Key
DTM 06-125A
Gray A-Key
DTM 06-12SA
Black B-Key
DTM 06-12SBA
DRC26-50S01
Wedge WM-12S WM-12S Not required
Strip length 3.96 to 5.54 mm
[0.156 to 0.218 in]
3.96 to 5.54 mm
[0.156 to 0.218 in]
3.96 to 5.54 mm
[0.156 to 0.218 in]
Real seal maximum
insulation OD
3.05 mm [0.120 in] 3.05 mm [0.120 in] 2.41 mm [0.095 in]
Sealing plugs 0413-204-2005 0413-204-2005 0413-204-2005
Danfoss mating connector part information
Description 12 pin module 24 pin module 50 pin module
Mating connector bag
assembly (20 to 24 AWG)
10100944 10100945 10100946
Mating connector bag
assembly (16 to 20 AWG)
10102025 10102023 10102024
Danfoss crimp extraction tool part information
Description Part number
Crimp tool for 20 to 24 AWG 10100745
Crimp tool for 16 to 20 AWG 10102028
Extraction tool DEUTSCH 114010; 12 AWG 11068808
Extraction tool DEUTSCH 0144-240-2005; 16 to 20, 20 to 24 AWG 10100744
Mounting
PLUS+1
®
MC0XX-1XX 12, 24, and 50 pin modules can be mounted in one of three ways:
•
End (bulkhead) installation
•
Up to 3 units stacked on one another
•
Individually side mounted
Care must be taken to insure that the module connector is positioned so that moisture drains away from
the connector.
Technical Information
PLUS+1® MC0XX-1XX Controller Family
Product installation and start-up
24 |
©
Danfoss | April 2018 L1321895 | BC00000227en-US0401
