Danfoss PTU 025 Instruction Manual

+DC 89
FASTENER TORQUE: M10 19Nm (14 FT -LB)
+DC 89
130BA860.10
1
5
4
3
2
8
10
9
FUSE
C J3
ONNECT
CH22 CH22 CH22
CTI25MB
FASTENER TORQUE: M10 19Nm (14 FT -LB)
CTI25MB
CH22 CH22 CH22
7
6
1) 24 V DC, 5 A 5) Load sharing
T1 output taps -DC +DC
Temp switch 88 89
106 104 105 6)
Control transformer fuses (2 or 4 pieces) (see Table 4.22 for part numbers)
2) Manual motor starters 7)
SMPS fuse (see Table 4.18 for part numbers)
3) 30 A fuse-protected power terminals 8)
Manual motor controller fuses (3 or 6 pieces) (see Table 4.20 for part numbers)
4) Line power 9)
Electrical fuses, enclosure types F1 and F2 (3 pieces) (see Table 4.12 to Table 4.16
for part numbers)
R S T 10) 30 Amp fuse-protected power fuses
L1 L2 L3
Figure 4.6 Rectier Cabinet, Enclosure Types F1, F2, F3 and F4
Electrical Installation
Instruction Manual
MG11F522 Danfoss A/S © 08/2014 All rights reserved. 43
4 4
