Danfoss PTU 025 Design Guide

1
st
digit 2
nd
digit
Level of protection
0 – No protection.
1 – Protected to 50 mm (2.0 in). No hands would be able to get into the enclosure.
2 – Protected to 12.5 mm (0.5 in). No ngers would be able to get into the enclosure.
3 – Protected to 2.5 mm (0.1 in). No tools would be able to get into the enclosure.
4 – Protected to 1.0 mm (0.04 in). No wires would be able to get into the enclosure.
5 – Protected against dust – limited entry
6 – Protected totally against dust
– 0 No protection
– 1 Protected from vertical dripping water
– 2
Protected from dripping water at 15° angle
– 3
Protected from water at 60° angle
– 4 Protected from splashing water
– 5 Protected from water jets
– 6 Protected from strong water jets
– 7 Protected from temporary immersion
– 8 Protected from permanent immersion
Table 3.3 IP Number Breakdown
Approvals and Certication... Design Guide
MG16C302 Danfoss A/S © 11/2017 All rights reserved. 11
3 3
