8.10
F11 Exterior and T
erminal Dimensions
8.10.1
F11
Exterior
Dimensions
130BF335.10
2280
(89.7)
2204
(86.8)
2400 (94.5)
606
(23.9)
776
(30.6)
776
(30.6)
776
(30.6)
Illustration
8.72
Front,
Side,
and
Door
Clearanc
e
Dimensions
for
F11
Exterior and T
erminal Dimen...
VL
T
®
HV
A
C Drive FC 102
136
Danfoss A/S © 11/2017 All rights reserved.
MG16C302
8
8
137
139
