Danfoss PVG 32 Application Guide

References
Related literature: PVG 32 Proportional Valve Group Technical Information, 520L0344, BC00000038
Terms and definitions
Term Definition
CB Counterbalance
FC Flow Control
NO Natural Oscillation
PC Pressure Control
Pl Load pressure
PVG Proportional Valve Group
Ql Work Port Flow
Important user information
Danfoss is not responsible or liable for indirect or consequential damages resulting from the use or
application of this equipment.
The examples and diagrams in this manual are included for illustration purposes. Due to the many
variables and requirements associated with any particular installation, Danfoss cannot assume
responsibility or liability for the actual used bases on the examples and diagrams.
Reproduction of whole or part of the contents of this manual is prohibited.
The following notes are used to raise awareness of safety considerations.
W
Warning
Xxxxx
Identifies information about practices or circumstances that can cause a hazardous
situation, which may lead to personal injury or death, damage or economic loss.
C
Caution
Xxxx
Identifies information about practices or circumstances that can lead to personal injury
or death, property damage, or economic loss. Attentions help you identify a hazard,
avoid a hazard, and recognize the consequence
Note
Identifies information that is critical for successful application and understanding of the
product.
Identifies a typical use of a functionality or parameter value. Use recommendations as a
starting point for the final configuration process of the system.
Application Guide
Using flow or pressure control spools
About this document
©
Danfoss | Feb 2017 AB00000079en-US0101 | 3

Danfoss PVG 32 Specifications

General

Category	Control Unit
Maximum working pressure	350 bar
Size	32
Type	Proportional Valve
Maximum operating pressure	420 bar
Porting pattern	ISO 4401
Electrical connection	AMP
