User Guide TP5001 Programmable Room Thermostats
Danfoss Heating
VUSUF102 | BC306936081288EN-000102 09/2020
9 Set Control Parameters
• Press M button for 6 seconds to enter the parameter setting mode. Press M for parameter selection and set
the parameter range via < or >. Complete all adjustments.
• To exit press , which is available for this purpose (automatic exit after 20 seconds with no operation).
The digits indicate the set value as follows:
No. Parameter settings Settings range Default
P01 Working mode
01: Manual
02: Schedule timer 5/2 day
03: Schedule timer 24hr
02
P02 Heat control mode
01: On/o load compensation
02: On/o standard
01
P03 Heat control start-up mode
01: Normal start control
02: Delayed start control
03: Optimised start control
01
P04 Temperature limit high Between low (P05) and 35° C 35° C
P05 Temperature limit low Between 5° C and high (P04) 5° C
P06 Frost protect temperature Between 5° C and 15° C 5° C
P07 Away mode temperature Between low (P05) and high (P04) 18° C
P08 Timer display
01: 24hr
02: 12hr
24hr
P09 Service due setup Installer setting only
P10 RF Pairing (TP5001RF only)
00: RF pairing mode o
01: RF pairing mode on
00
P11 Auto daylight saving
01: On
02: O
01
10 Error Messages
E1 Sensor failure
EE EEPROM failure
Lo Measured temperature below 0 °C
Hi Measured temperature above 50 °C
E3 RF Pairing failed
E4 RF Signal lost
