Response telegram from VLT
®
frequency converter to master (PC or PLC)
Function Byte no. ASCII character Decimal value
Start byte 1 < 60
2048
3149
Control character 4 U 85
5G71
6H72
7K75
8@64
9048
10 5 53
11 1 49
12 6 54
Sign 13 + 43
14 0 48
15 0 48
16 0 48
17 8 56
18 0 48
Comma 19 0 48
20 0 48
21 7 55
Stop byte 22 > 62
Check sum: Byte 2-19 = 1007 reduced to 07
Status word equivalent to the example on p. 79.
Serial data interface,
group 5..
(continued)
Fault reports parameters (read/write)
Byte 19 in the response telegram from the
VLT
®
frequency converter assumes the
value 9 if it is not possible to perform the
selected write or read command, and
simultaneously a reason code is given in
bytes 17 and 18. The following reason
codes are found:
Address
Control/status word
Parameter no.
Data value
Check sum
Switch 04:
The drawing on p. 147 shows the position
of switch 04.
04 closed: Terminal 61 is connected
directly to earth.
04 open: Terminal 61 is connected to
earth via an RC link.
When switch 04 is closed, there is no
galvanic separation between the signal
cables (terminals 68 and 69) and earth,
which can give problems if a master
without galvanic separation is used.
Therefore the following connection method
should be used: Switch 04 must be open,
the signal cable’s screen must be con-
nected to the relief stirrup below the control
card, but not to terminal 61.
The screen is uncovered and clamped
under the relief stirrup, the screen may not
end at the relief stirrup, but must be led as
close to the terminal block as possible, so
that the unscreened signal cable ends are
as short as possible.
Code Reason
00 Parameter number does not exist
01 There is no read/write access to
the selected parameter
02 A non-existent index no. has
been selected
03 Index reading is used for a
parameter which does not
have indexes
04 The parameter is read-only.
Can be because factory setup has
been selected
05 The parameter cannot be changed
when the motor is running
06 The data value is outside the
parameter’s range
07 Illegal comma value (byte 19)
08 The read data value > 99999
99 Other faults
