VLT® 5000 Crane
PNU Parameter Range Factory setting Changes Unit Conversion Data Protection
#
0xx
description
Operation and display
during
operation
index index type level
001 Language English Yes 0 0 5 2
002 Operation site Remote control Yes 0 0 5 2
003 Local reference 0Yes0-342
007 LCP copy No copy No 0 0 5 0
009 Display linie 2 Speed [RPM] Yes 0 0 5 2
010 Displayline1.1 Reference [%] Yes 0 0 5 2
011 Displayline1.2 Motor current [A] Yes 0 0 5 2
012 Displayline1.3 Power [kW] Yes 0 0 5 2
014 LCP stop Enable Yes 0 0 5 1
015 LCP jogging Disable Yes 0 0 5 1
016 LCP reversing Disable Yes 0 0 5 1
017 LCP reset of trip Enable Yes 0 0 5 2
018 Lock for data change Not locked Yes 0 0 5 1
1xx Motor and Load
100 Configuration Speed control,
closed loop
No 0 0 5 2
102 Motor power 0.18 - 500 kW Depends on unit No 9 1 6 1
103 Motor voltage 200 - 500 V Depends on unit No 21 0 6 1
104 Motor frequency 24 - 1000Hz Depends on unit No 28 0 6 1
105 Motor current 0.01 - 1
VLT,MAX
Depends on unit No 22 -2 7 1
106 Rated motor speed 100 - 60000
rpm
Depends on unit No 11 67 6 1
122 Function at stop Coast Yes 0 0 5 1
124 DC-hold current 0 - 100% 50% Yes 27 0 6 1
128 Motor thermal
protection
No protection Yes 0 0 5 1
150 Stator resistance Depends on unit No 23 -4 7 1
151 Rotor resistance Depends on unit No 23 -4 7 1
152 Stator leakage Depends on unit No 23 -3 7 1
153 Rotor leakage Depends on unit No 23 -3 7 1
154 Main reactance Depends on unit No 23 -3 7 1
155 Rotor inertia Depends on unit No 0 -4 7 1
156 Pole number 4No0051
157 Field weakening
speed
0 - 6000RPM Depends on unit No 11 67 6 1
158 Ironloss resistance 1 - 10000 10000 No 23 0 6 1
✭ = factory setting. () = display text [] = value for use in communication via serial communication port
MG.50.N4.02 - VLT is a registered Danfoss trademark
44
