1
7
8
10
12
6
5
11
9
4
2
3
130BF857.10
1 MK1802 7 Inrush card
2 MK1800 8 Screw (T20)
3 Screw (T20) 9 MK101
4 MK102 10 Gate drive card
5 MK100 11 MK701
6 MK501 12 MK601
Illustration 11.9 Inrush Card and Gate Drive Card
