Danfoss VLT AQUA Drive FC 202

e30bg395.10
1
6
2
3
7
8
4
9
10
5
1 Screwdriver access holes for captive screws (T25) 6 Mixing fan
2 Mounting studs 7 Cable grommet
3 Slot for fan cover 8 Fan cable connector
4 Heat sink fan 9 Fan cover
5 Mounting holes 10 Fan cover tabs
Illustration 11.32 Heat Sink Fan in IP20/Chassis Drives
D2h/D4h/D7h/D8h/J9 Unit Dis...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
234 Danfoss A/S © 02/2019 All rights reserved. MG94A502
