Danfoss VLT AQUA FC 202 User Manual

Mains Supply 3x525-690 V AC
P132 P160 P200 P250
Typical Shaft output at 550 V
[kW]
110 132 160 200
Typical Shaft output at 575 V
[HP]
150 200 250 300
Typical Shaft output at 690 V
[kW]
132 160 200 250
Enclosure IP21 D1 D1 D2 D2
Enclosure IP54 D1 D1 D2 D2
Enclosure IP00 D3 D3 D4 D4
Output current
Continuous
(at 550 V) [A]
162 201 253 303
Intermittent (60 sec overload)
(at 550 V) [A]
178 221 278 333
Continuous
(at 575/ 690 V) [A]
155 192 242 290
Intermittent (60 sec overload)
(at 575/ 690 V) [A]
171 211 266 319
Continuous KVA
(at 550 V) [KVA]
154 191 241 289
Continuous KVA
(at 575 V) [KVA]
154 191 241 289
Continuous KVA
(at 690 V) [KVA]
185 229 289 347
Max. input current
Continuous
(at 550 V ) [A]
158 198 245 299
Continuous
(at 575 V) [A]
151 189 234 286
Continuous
(at 690 V) [A]
155 197 240 296
Max. cable size, mains motor,
load share and brake [mm
2
(AWG)]
2 x 70 (2 x 2/0) 2 x 70 (2 x 2/0) 2 x 150 (2 x 300 mcm) 2 x 150 (2 x 300 mcm)
Max. external pre-fuses [A]
1
315 350 350 400
Estimated power loss
at rated max. load [W]
4)
, 600 V
2963 3430 4051 4867
Estimated power loss
at rated max. load [W]
4)
, 690 V
3430 3612 4292 5156
Weight,
Enclosure IP21, IP 54 [kg]
96 104 125 136
Weight,
Enclosure IP00 [kg]
82 91 112 123
Efficiency
4)
0.98
Output frequency 0 - 600 Hz
Heat sink overtemp. trip
90 °C 110°C 110 °C 110 °C
Power card ambient trip
60 °C
Table 6.5
General Specifications
VLT AQUA Drive FC 202 Operation Instructions
MG20P402 - Rev. 2013-12-16 125
