1) For type of fuse see section Fuses.
2) American Wire Gauge.
3) Measured using 5 m screened motor cables at rated load and rated frequency.
4) The typical power loss is at nominal load conditions and expected to be within +/-15% (tolerence relates to
variety in voltage and cable conditions). Values are based on a typical motor efficiency (eff2/eff3 border line).
Motors with lower efficiency will also add to the power loss in the frequency converter and opposite. If the
switching frequency is increased comed to the default setting, the power losses may rise significantly. LCP and
typical control card power consumptions are included. Further options and customer load may add up to 30 W to
the losses. (Though typical only 4 W extra for a fully loaded control card, or options for slot A or slot B, each).
Although measurements are made with state of the art equipment, some measurement inaccuracy must be
allowed for (+/-5%).
General Specifications VLT AQUA Drive FC 202 Operation Instructions
MG20P402 - Rev. 2013-12-16 129
