No. Description Warning Alarm/Trip Alarm/Trip Lock Parameter
Reference
220 Overload Trip X
98 Clock Fault X 0-7*
243 Brake IGBT X X
244 Heatsink temp X X X
245 Heatsink sensor X X
246 Pwr.card supply X X
247 Pwr.card temp X X
248 Illegal PS config X X
250 New spare part X
251 New Type Code X X
Table 7.1 Alarm/Warning Code List
(X) Dependent on parameter
1) Cannot be Auto reset via 14-20 Reset Mode
A trip is the action when an alarm has appeared. The trip coasts the motor and can be reset by pressing [Reset] or making a
reset by a digital input (Par. 5-1* Digital Inputs [1] Reset). The origin event that caused an alarm cannot damage the
frequency converter or cause dangerous conditions. A trip lock is an action when an alarm occurs, which may cause
damage to frequency converter or connected parts. A Trip Lock situation can only be reset by a power cycling.
LED indication
Warning yellow
Alarm flashing red
Trip locked yellow and red
Table 7.2
Troubleshooting VLT AQUA Drive FC 202 Operation Instructions
132 MG20P402 - Rev. 2013-12-16
