Danfoss VLT AQUA FC 202 User Manual

Enclosure type Size D1 D2 D3 D4
110-132 kW at 400 V
(380-480 V)
45-160 kW at 690 V
(525-690 V)
160-250 kW at 400 V
(380-480 V)
200-400 kW at 690 V
(525-690 V)
110-132 kW at 400 V
(380-480 V)
45-160 kW at 690 V
(525-690 V)
160 - 250 kW
at 400 V
(380-480 V)
200-400 kW
at 690 V
(525-690 V)
IP
NEMA
21
Type 1
54
Type 12
21
Type 1
54
Type 12
00
Chassis
00
Chassis
Shipping
dimensions
[mm]
Height
650 650 650 650 650 650
Width 1730 1730 1730 1730 1220 1490
Depth 570 570 570 570 570 570
Frequency
converter
dimensions
[mm]
Height 1209 1209 1589 1589 104 1327
Width 420 420 420 420 408 408
Depth 380 380 380 380 375 375
Max
weight
[kg]
104 104 151 151 91 138
Table 3.3 Mechanical dimensions, Enclosure type D
How to Install VLT AQUA Drive FC 202 Operation Instructions
MG20P402 - Rev. 2013-12-16 17
3 3
