Danfoss VLT AQUA FC 202 User Manual

2
5
6
4, 8, 9
130BA861.11
1
1) External Temperature Monitoring 6) Motor
2) AUX Relay U V W
01 02 03 96 97 98
04 05 06 T1 T2 T3
3) NAMUR 7) NAMUR Fuse. See fuse tables for part numbers
4) AUX Fan 8) Fan Fuses. See fuse tables for part numbers
100 101 102 103 9) SMPS Fuses. See fuse tables for part numbers
L1 L2 L1 L2
5) Brake
-R +R
81 82
Illustration 3.65 Inverter Cabinet, Enclosure Types F1 and F3
How to Install
VLT AQUA Drive FC 202 Operation Instructions
50 MG20P402 - Rev. 2013-12-16
