GLCP keys
Menu keys
The menu keys are divided into functions. The keys below
the display and indicator lamps are used for parameter set-
up, including choice of display indication during normal
operation.
130BP045.10
Status
Quick
Menu
Main
Menu
Alarm
Log
Illustration 4.7 Menu Keys
[Status]
Indicates the status of the frequency converter and/or the
motor. 3 different readouts can be chosen by pressing the
[Status] key:
5 line readouts, 4 line readouts or Smart Logic Control.
Use [Status] for selecting the mode of display or for
changing back to Display mode from either the Quick
Menu mode, the Main Menu mode or Alarm mode. Also
use the [Status] key to toggle single or double read-out
mode.
[Quick Menu]
Allows quick set-up of the frequency converter. The most
common functions can be programmed here.Quick Menu
The [Quick Menu] consists of:
•
Q1: My Personal Menu
•
Q2: Quick Setup
•
Q3: Function Setups
•
Q5: Changes Made
•
Q6: Loggings
The Function Set-up provides quick and easy access to all
parameters required for the majority of water and
wastewater applications including variable torque, constant
torque, pumps, dosing pumps, well pumps, booster
pumps, mixer pumps, aeration blowers and other pump
and fan applications. Amongst other features it also
includes parameters for selecting which variables to display
on the LCP, digital preset speeds, scaling of analog
references, closed loop single zone and multi-zone
applications and specific functions related to water and
wastewater applications.
The Quick Menu parameters can be accessed immediately
unless a password has been created via 0-60 Main Menu
Password, 0-61 Access to Main Menu w/o Password,
0-65 Personal Menu Password or 0-66 Access to Personal
Menu w/o Password.
It is possible to switch directly between Quick Menu mode
and Main Menu mode.
[Main Menu]
is used for programming all parameters.
The Main Menu parameters can be accessed immediately
unless a password has been created via 0-60 Main Menu
Password, 0-61 Access to Main Menu w/o Password,
0-65 Personal Menu Password or 0-66 Access to Personal
Menu w/o Password. For the majority of water and
wastewater applications it is not necessary to access the
Main Menu parameters but instead the Quick Menu, Quick
Setup and Function Setups provides the simplest and
quickest access to the typical required parameters.
It is possible to switch directly between Main Menu mode
and Quick Menu mode.
Parameter shortcut can be carried out by pressing down
the [Main Menu] key for 3 seconds. The parameter shortcut
allows direct access to any parameter.
[Alarm Log]
displays an Alarm list of the five latest alarms (numbered
A1-A5). To obtain additional details about an alarm, use
the navigation keys to manoeuvre to the alarm number
and press [OK]. Information is displayed about the
condition of the frequency converter before it enters the
alarm mode.
[Back]
reverts to the previous step or layer in the navigation
structure.
B
a
c
k
Illustration 4.8 Back Key
[Cancel]
last change or command is cancelled as long as the
display has not been changed.
C
a
n
c
e
l
Illustration 4.9 Cancel Key
[Info]
displays information about a command, parameter, or
function in any display window. [Info] provides detailed
information when needed.
Exit Info mode by pressing either [Info], [Back], or [Cancel].
I
n
f
o
Illustration 4.10 Info Key
Navigation keys
The 4 navigation keys are used to navigate between the
different choices available in [Quick Menu], [Main Menu]
and [Alarm Log]. Use the keys to move the cursor.
How to operate the frequenc...
