Danfoss VLT AutomationDrive FC 300 Series Operating Instructions

Mains Supply 525-690 V AC
FC 302
P900 P1M0 P1M2
High/ Normal Load* HO NO HO NO HO NO
Typical Shaft output at 550 V [kW] 750 850 850 1000 1000 1100
Typical Shaft output at 575 V [hp] 1050 1150 1150 1350 1350 1550
Typical Shaft output at 690 V [kW] 900 1000 1000 1200 1200 1400
Enclosure IP21, IP54 without/with options
cabinet
F2/ F4 F2/ F4 F2/ F4
Output current
Continuous
(at 550 V) [A]
988 1108 1108 1317 1317 1479
Intermittent (60 s overload)
(at 550 V) [A]
1482 1219 1662 1449 1976 1627
Continuous
(at 575/690 V) [A]
945 1060 1060 1260 1260 1415
Intermittent (60 s overload)
(at 575/690 V) [A]
1418 1166 1590 1386 1890 1557
Continuous KVA
(at 550 V) [KVA]
941 1056 1056 1255 1255 1409
Continuous KVA
(at 575 V) [KVA]
941 1056 1056 1255 1255 1409
Continuous KVA
(at 690 V) [KVA]
1129 1267 1267 1506 1506 1691
Max. input current
Continuous
(at 550 V ) [A]
962 1079 1079 1282 1282 1440
Continuous
(at 575 V) [A]
920 1032 1032 1227 1227 1378
Continuous
(at 690 V) [A]
920 1032 1032 1227 1227 1378
Max. cable size, motor [mm
2
(AWG
2)
)]
12x150
(12x300 mcm)
Max. cable size,mains F2 [mm
2
(AWG
2)
)]
8x240
(8x500 mcm)
Max. cable size,mains F4 [mm
2
(AWG
2)
)]
8x456
(8x900 mcm)
Max. cable size, loadsharing [mm
2
(AWG
2)
)]
4x120
(4x250 mcm)
Max. cable size, brake [mm
2
(AWG
2)
)
6x185
(6x350 mcm)
Max. external mains fuses [A]
1
1600 2000 2500
Estimated power loss, 600V [W]
4)
11329 12909 12570 15358 15258 17602
Estimated power loss, 690V [W]
4)
11681 13305 12997 15865 15763 18173
F3/F4 Max added losses CB or Disconnect
& Contactor
556 665 634 863 861 1044
Max panel options losses 400
Weight,
enclosure IP21, IP54 [kg]
1246/ 1541 1246/ 1541 1280/1575
Weight, Rectifier Module [kg] 136 136 136
Weight, Inverter Module [kg] 102 102 136
Efficiency
4)
0.98
Output frequency 0-500Hz
Heatsink overtemp. trip
105°C 105°C 95°C
Power card ambient trip
75°C
* High overload = 160% torque during 60 s., Normal overload = 110% torque during 60 s.
Table 5.9
