Danfoss VLT Brake Resistor MCE 101

40% duty cycle, vertical braking, T2
FC 202 Vertical braking 40% duty cycle
Frequency converter data
Brake resistor data Installation
R
rec
[Ω]
P
br,cont.
[kW]
Danfoss part number
Cable
cross-
section
[mm
2
]
Thermo
relay
[A]
Mains
type
P
m
[kW]
R
min
[Ω]
R
br,nom
[Ω]
Wire IP54
Screw
terminal
IP21
Screw
terminal
IP65
Bolt
connection
IP20
T2 0.25 380 691.3 630 0.100 175u3002 - - - 1.5 0.4
T2 0.37 380 466.7 410 0.100 175u3004 - - - 1.5 0.5
T2 0.55 275 313.7 300 0.200 175u3096 - - - 1.5 0.8
T2 0.75 188 230.0 200 0.200 175u3008 - - - 1.5 0.9
T2 1.1 130 152.9 145 0.300 175u3300 - - - 1.5 1.3
T2 1.5 81.0 110.5 100 0.450 175u3301 175u3402 175u3401 - 1.5 2
T2 2.2 58.5 74.1 70 0.570 175u3302 175u3404 175u3403 - 1.5 2.7
T2 3 45.0 53.7 48 0.960 175u3303 175u3406 175u3405 - 1.5 4.2
T2 3.7 31.5 39.9 35 1.130 175u3304 175u3408 175u3407 - 1.5 5.4
T2 5.5 22.5 28.7 27 1.400 175u3305 175u3410 175u3409 - 1.5 6.8
T2 7.5 17.7 20.8 18 2.200 175u3306 175u3412 175u3411 - 1.5 10.4
T2 11 12.6 14.0 13 3.200 175u3307 175u3414 175u3413 - 2.5 14.7
T2 15 8.7 10.2 9.0 5.500 - 175u3176 175u3177 - 4 23
T2 18.5 5.3 8.2 5.7 6.000 - - - 175u3233 10 33
T2 22 5.1 6.9 5.7 8.000 - - - 175u3234 10 38
T2 30 3.2 5.0 3.5 9.000 - - - 175u3235 16 51
T2 37 3.0 4.1 3.5 14.000 - - - 175u3224 25 63
T2 45 2.4 3.3 2.8 17.000 - - - 175u3227 35 78
Table 8.12 T2, Vertical Braking 40% Duty Cycle
Selection Guide Design Guide
42 Danfoss A/S © Rev. 05/2014 All rights reserved. MG90O202
