8.3.6
VLT
®
AutomationDrive FC 301, T2
Mains: 200-240 V, T2
FC 301
P
m
R
min
R
br,nom
Flat-pack IP65
R
rec
per item/P
br,cont.
Duty cycle Danfoss part number
T2 [kW] [Ω] [Ω] [Ω/W] % 175Uxxxx
PK25 0.25 368 415.9 430/100 40 1002
PK37 0.37 248 280.7 330/100 27 1003
PK37 0.37 248 280.7 310/200 55 0984
PK55 0.55 166 188.7 220/100 20 1004
PK55 0.55 166 188.7 210/200 37 0987
PK75 0.75 121 138.4 150/100 14 1005
PK75 0.75 121 138.4 150/200 27 0989
P1K1 1.1 81.0 92.0 100/100 10 1006
P1K1 1.1 81.0 92.0 100/200 19 0991
P1K5 1.5 58.5 66.5 72/200 14 0992
P2K2 2.2 40.2 44.6 50/200 10 0993
P3K0 3 29.1 32.3 35/200 7 0994
P3K0 3 29.1 32.3 72/200 14 2x0992
P3K7 3.7 22.5 25.9 40/200 11 2x0996
Table 8.41 Mains: 200-240 V (T2)
8.3.7
VLT
®
AutomationDrive FC 302, T2
Mains: 200-240 V, T2
FC 302
P
m
R
min
R
br,nom
Flat-pack IP65
R
rec
per item/P
br,cont.
Duty cycle Danfoss part number
T2 [kW] [Ω] [Ω] [Ω/W] % 175Uxxxx
PK25 0.25 380 475.3 430/100 40 1002
PK37 0.37 275 320.8 330/100 27 1003
PK37 0.37 275 320.8 310/200 54 0984
PK55 0.55 188 215.7 220/100 18 1004
PK55 0.55 188 215.7 210/200 36 0987
PK75 0.75 130 158.1 150/100 13 1005
PK75 0.75 130 158.1 150/200 27 0989
P1K1 1.1 81.0 105.1 100/100 9 1006
P1K1 1.1 81.0 105.1 100/200 18 0991
P1K5 1.5 58.5 76.0 72/200 13 0992
P2K2 2.2 45.0 51.0 50/200 9 0993
P3K0 3 31.5 37.0 35/200 7 0994
P3K0 3 31.5 37.0 72/200 14 2x0992
P3K7 3.7 22.5 29.7 40/200 10 2x0996
Table 8.42 Mains: 200-240 V (T2)
Selection Guide Design Guide
64 Danfoss A/S © Rev. 05/2014 All rights reserved. MG90O202
