Danfoss VLT Brake Resistor MCE 101 User Manual

10% duty cycle, horizontal braking, T5
FC 302 Horizontal braking 10% duty cycle
Frequency converter data
Brake resistor data Installation
R
rec
[Ω]
P
br,cont.
[kW]
Danfoss part number
Cable
cross-
section
[mm
2
]
Thermo
relay
[A]
Mains
type
P
m
[kW]
R
min
[Ω]
R
br,nom
[Ω]
Wire IP54
Screw
terminal
IP21
Screw
terminal
IP65
Bolt
connection
IP20
T5 0.37 1000 1389.2 1200 0.100 175u3000 - - - 1.5 0.3
T5 0.55 620 928.8 850 0.100 175u3001 - - - 1.5 0.4
T5 0.75 558 678.3 630 0.100 175u3002 - - - 1.5 0.4
T5 1.1 382 452.5 410 0.100 175u3004 - - - 1.5 0.5
T5 1.5 260 325.9 270 0.200 175u3007 - - - 1.5 0.8
T5 2.2 189 218.6 200 0.200 175u3008 - - - 1.5 0.9
T5 3 135 158.5 145 0.300 175u3300 - - - 1.5 1.3
T5 4 99.0 117.2 110 0.450 175u3335 175u3450 175u3449 - 1.5 1.9
T5 5.5 72.0 84.4 80 0.570 175u3336 175u3452 175u3451 - 1.5 2.5
T5 7.5 50.0 61.4 56 0.680 175u3337 175u3027 175u3028 - 1.5 3.3
T5 11 36.0 41.2 38 1.130 175u3338 175u3034 175u3035 - 1.5 5.2
T5 15 27.0 30.0 28 1.400 175u3339 175u3039 175u3040 - 1.5 6.7
T5 18.5 20.3 24.2 22 1.700 175u3340 175u3047 175u3048 - 1.5 8.3
T5 22 18.0 20.3 19 2.200 175u3357 175u3049 175u3050 - 1.5 10.1
T5 30 13.4 15.8 14 2.800 175u3341 175u3055 175u3056 - 2.5 13.3
T5 37 10.8 12.7 12 3.200 175u3359 175u3061 175u3062 - 2.5 15.3
T5 45 8.8 10.4 9.5 4.200 - 175u3065 175u3066 - 4 20
T5 55 6.5 8.5 7.0 5.500 - 175u3070 175u3071 - 6 26
T5 75 4.2 6.2 5.5 7.000 - - - 175u3231 10 36
T5 90 3.6 5.1 4.7 9.000 - - - 175u3079 16 44
T5 110 3.0 4.2 3.7 11.000 - - - 175u3083 25 55
T5 132 2.5 3.5 3.3 13.000 - - - 175u3084 35 63
T5 160 2.0 2.9 2.7 16.000 - - - 175u3088 50 77
T5 200 1.6 2.3 2.1 20.000 - - - 175u3091 70 98
T5 250 1.2 1.8 1.7 26.000 - - - 175u3093 2x35 124
T5 315 1.2 1.5 1.3 32.000 - - - 175u3097 2x35 157
T5 355 1.2 1.3 1.2 36.000 - - - 175u3098 2x50 173
T5 400 1.1 1.1 1.1 42.000 - - - 175u3099 2x50 196
T5 450 0.9 1.0 2x1.9 - - - - - - -
T5 500 0.9 0.9 2x1.7 - - - - - - -
T5 560 0.8 0.8 2x1.5 - - - - - - -
T5 630 0.7 0.7 2x1.3 - - - - - - -
T5 710 0.6 0.6 3x1.8 - - - - - - -
T5 800 0.5 0.6 3x1.6 - - - - - - -
Table 8.25 T5, Horizontal Braking 10% Duty Cycle
Selection Guide
Design Guide
52 Danfoss A/S © Rev. 05/2014 All rights reserved. MG90O202
88
