Danfoss VLT Brake Resistor MCE 101 User Manual

10% duty cycle, horizontal braking, T6
FC 302 Horizontal braking 10% duty cycle
Frequency converter data
Brake resistor data Installation
R
rec
[Ω]
P
br,cont.
[kW]
Danfoss part number
Cable
cross-
section
[mm
2
]
Thermo
relay
[A]
Mains
type
P
m
[kW]
R
min
[Ω]
R
br,nom
[Ω]
Wire IP54
Screw
terminal
IP21
Screw
terminal
IP65
Bolt
connection
IP20
T6 0.75 620 914.2 850 0.100 175u3001 - - - 1.5 0.4
T6 1.1 550 611.3 570 0.100 175u3003 - - - 1.5 0.4
T6 1.5 380 441.9 415 0.200 175u3005 - - - 1.5 0.7
T6 2.2 260 296.4 270 0.200 175u3007 - - - 1.5 0.8
T6 3 189 214.8 200 0.300 175u3342 - - - 1.5 1.1
T6 4 135 159.2 145 0.450 175u3343 175u3012 175u3013 - 1.5 1.7
T6 5.5 99.0 114.5 100 0.570 175u3344 175u3136 175u3137 - 1.5 2.3
T6 7.5 69.0 83.2 72 0.680 175u3345 175u3456 175u3455 - 1.5 2.9
T6 11 48.6 56.1 52 1.130 175u3346 175u3458 175u3457 - 1.5 4.4
T6 15 35.1 40.8 38 1.400 175u3347 175u3460 175u3459 - 1.5 5.7
T6 18.5 27.0 32.9 31 1.700 175u3348 175u3037 175u3038 - 1.5 7
T6 22 22.5 27.6 27 2.200 175u3349 175u3043 175u3044 - 1.5 8.5
T6 30 17.1 21.4 19 2.800 175u3350 175u3462 175u3461 - 2.5 11.4
T6 37 13.5 17.3 14 3.200 175u3358 175u3464 175u3463 - 2.5 14.2
T6 45 10.8 14.2 13.5 4.200 - 175u3057 175u3058 - 4 17
T6 55 8.8 11.6 11 5.500 - 175u3063 175u3064 - 6 21
T6 75 6.6 8.4 7.0 7.000 - - - 175u3245 10 32
Table 8.27 T6, Horizontal Braking 10% Duty Cycle
40% duty cycle, vertical braking, T6
FC 302 Vertical braking 40% duty cycle
Frequency converter data
Brake resistor data Installation
R
rec
[Ω]
P
br,cont.
[kW]
Danfoss part number
Cable
cross-
section
[mm
2
]
Thermo
relay
[A]
Mains
type
P
m
[kW]
R
min
[Ω]
R
br,nom
[Ω]
Wire IP54
Screw
terminal
IP21
Screw
terminal
IP65
Bolt
connection
IP20
T6 0.75 620 914.2 850 0.280 175u3317 175u3104 175u3105 - 1.5 0.6
T6 1.1 550 611.3 570 0.450 175u3318 175u3430 175u3429 - 1.5 0.9
T6 1.5 380 441.9 415 0.570 175u3319 175u3432 175u3431 - 1.5 1.1
T6 2.2 260 296.4 270 0.960 175u3320 175u3434 175u3433 - 1.5 1.8
T6 3 189 214.8 200 1.130 175u3321 175u3436 175u3435 - 1.5 2.3
T6 4 135 159.2 145 1.700 175u3322 175u3126 175u3127 - 1.5 3.3
T6 5.5 99.0 114.5 100 2.200 175u3323 175u3438 175u3437 - 1.5 4.4
T6 7.5 69.0 83.2 72 3.200 175u3324 175u3440 175u3439 - 1.5 6.3
T6 11 48.6 56.1 52 5.500 - 175u3148 175u3149 - 1.5 9.7
T6 15 35.1 40.8 38 6.000 - - - 175u3239 2.5 12.6
T6 18.5 27.0 32.9 31 8.000 - - - 175u3240 4 16
T6 22 22.5 27.6 27 10.000 - - - 175u3200 4 19
T6 30 17.1 21.4 19 14.000 - - - 175u3204 10 27
T6 37 13.5 17.3 14 17.000 - - - 175u3207 10 35
T6 45 10.8 14.2 13.5 21.000 - - - 175u3208 16 40
T6 55 8.8 11.6 11 26.000 - - - 175u3211 25 49
T6 75 6.6 8.4 7.0 30.000 - - - 175u3241 35 66
Table 8.28 T6, Vertical Braking 40% Duty Cycle
Selection Guide Design Guide
54 Danfoss A/S © Rev. 05/2014 All rights reserved. MG90O202
