Danfoss VLT Brake Resistor MCE 101

40% duty cycle, vertical braking, T4
FC 360 Vertical braking 40% duty cycle
Frequency converter data
Brake resistor data Installation
R
rec
[Ω]
P
br,cont.
[kW]
Danfoss part number
Cable
cross-
section
[mm
2
]
Thermo
relay
[A]
Mains
type
P
m
[kW]
R
min
[Ω]
R
br,nom
[Ω]
Wire IP54
Screw
terminal
IP21
Screw
terminal
IP65
Bolt
connection
IP20
T4 0.37 890 1042 1200 0.200 175u3101 - - - 1.5 0.4
T4 0.55 593 694 850 0.200 175u3308 - - - 1.5 0.5
T4 0.75 434 509 630 0.300 175u3309 - - - 1.5 0.7
T4 1.1 288 338 410 0.450 175u3310 175u3416 175u3415 - 1.5 1
T4 1.5 208 244 270 0.570 175u3311 175u3418 175u3417 - 1.5 1.4
T4 2.2 139 164 200 0.960 175u3312 175u3420 175u3419 - 1.5 2.1
T4 3 100 119 145 1.130 175u3313 175u3422 175u3421 - 1.5 2.7
T4 4 74.0 87.9 110 1.700 175u3314 175u3424 175u3423 - 1.5 3.7
T4 5.5 54.0 63.3 80 2.200 175u3315 175u3138 175u3139 - 1.5 5
T4 7.5 38.0 46.1 56 3.200 175u3316 175u3428 175u3427 - 1.5 7.1
T4 11 27.0 33.0 38 5.000 - - - 175u3236 1.5 11.5
T4 15 19.0 24.0 28 6.000 - - - 175u3237 2.5 14.7
T4 18.5 16.0 19.4 22 8.000 - - - 175u3238 4 19
T4 22 16.0 18.0 19 10.000 - - - 175u3203 4 23
T4 30 11.0 13.8 14 14.000 - - - 175u3206 10 32
T4 37 9.0 11.1 12 17.000 - - - 175u3210 10 38
T4 45 8.0 9.1 9.5 21.000 - - - 175u3213 16 47
T4 55 6.0 7.4 7.0 26.000 - - - 175u3216 25 61
T4 75 4.0 5.4 5.5 36.000 - - - 175u3219 35 81
Table 8.32 T4, Vertical Braking 40% Duty Cycle
Selection Guide Design Guide
58 Danfoss A/S © Rev. 05/2014 All rights reserved. MG90O202
