Danfoss VLT Brake Resistor MCE 101

Danfoss P/N Typecode
[Ω]
L ±2 mm L ±0.08 in L1 ±2 mm L1 ±0.04 in
Weight
[kg]
175U3032 MCE101A42R0P1K70E21TAW 42 460 18.11 360 14.17 9.2
175U3037 MCE101A31R0P1K70E21TAW 31 460 18.11 360 14.17 9.2
175U3039 MCE101A28R0P1K40E21TAW 28 400 15.75 300 11.81 8.2
175U3043 MCE101A27R0P2K20E21TAW 27 560 22.05 460 18.11 11
175U3047 MCE101A22R0P1K70E21TAW 22 460 18.11 360 14.17 9.2
175U3049 MCE101A19R0P2K20E21TAW 19 560 22.05 460 11.81 11
175U3055 MCE101A14R0P2K80E21TAW 14 660 25.98 560 22.05 12.8
175U3061 MCE101A12R0P3K20E21TAW 12 760 29.92 660 25.98 14.6
175U3073 MCE101A5R70P1K40E21TAW 5.7 400 15.75 300 11.81 8.2
175U3080 MCE101A3R50P2K20E21TAW 3.5 560 22.05 460 11.81 11
175U3086 MCE101A2R80P3K20E21TAW 2.8 760 29.92 660 25.98 14.6
175U3106 MCE101A145RP2K20E21TAW 145 560 22.05 460 11.81 11
175U3122 MCE101A200RP1K70E21TAW 200 460 18.11 360 14.17 9.2
175U3126 MCE101A145RP1K70E21TAW 145 460 18.11 360 14.17 9.2
175U3130 MCE101A110RP2K20E21TAW 110 560 22.05 460 18.11 11
175U3132 MCE101A105RP3K20E21TAW 105 760 29.92 660 25.98 14.6
175U3138 MCE101A80R0P2K20E21TAW 80 560 22.05 460 18.11 11
175U3140 MCE101A72R0P2K80E21TAW 72 660 25.98 560 22.05 12.8
175U3146 MCE101A56R0P2K80E21TAW 56 660 25.98 560 22.05 12.8
175U3152 MCE101A48R0P1K40E21TAW 48 400 15.75 300 11.81 8.2
175U3160 MCE101A35R0P1K70E21TAW 35 460 18.11 360 14.17 9.2
175U3168 MCE101A27R0P2K20E21TAW 27 560 22.05 460 18.11 11
175U3172 MCE101A18R0P3K20E21TAW 18 760 29.92 660 25.98 14.6
175U3410 MCE101A27R0P1K40E21TAW 27 400 15.75 300 11.81 8.2
175U3412 MCE101A18R0P2K20E21TAW 18 560 22.05 460 18.11 11
175U3414 MCE101A13R0P3K20E21TAW 13 760 29.92 660 25.98 14.6
175U3424 MCE101A110RP1K70E21TAW 110 460 18.11 360 14.17 9.2
175U3428 MCE101A56R0P3K20E21TAW 56 760 29.92 660 25.98 14.6
175U3438 MCE101A100RP2K20E21TAW 100 560 22.05 460 18.11 11
175U3440 MCE101A72R0P3K20E21TAW 72 760 29.92 660 25.98 14.6
175U3446 MCE101A5R70P1K40E21TAW 5.7 400 15.75 300 11.81 8.2
175U3448 MCE101A3R50P2K80E21TAW 3.5 660 25.98 560 22.05 12.8
175U3460 MCE101A38R0P1K40E21TAW 38 400 15.75 300 11.81 8.2
175U3462 MCE101A19R0P2K80E21TAW 19 660 25.98 560 22.05 12.8
175U3464 MCE101A14R0P3K20E21TAW 14 760 29.92 660 25.98 14.6
175U3468 MCE101A52R0P1K40E21TAW 52 400 15.75 300 11.81 8.2
175U3470 MCE101A31R0P2K20E21TAW 31 560 22.05 460 18.11 11
175U3472 MCE101A27R0P2K80E21TAW 27 660 25.98 560 22.05 12.8
175U3479 MCE101A22R0P3K20E21TAW 22 760 29.92 660 25.98 14.6
175U3483 MCE101A5R70P1K70E21TAW 5.7 460 18.11 360 14.17 9.2
Table 9.5 Mechanical Dimensions
