Parameter 5-63 Terminal 29 Pulse Output Variable
Table 377: Parameter 5-63 Terminal 29 Pulse Output Variable
5-63 Terminal 29 Pulse Output Variable
Default value: Size related
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Option
Name
Description
[0]
No operation
Select the display output for terminal 27.
[45]
Bus ctrl.
[48]
Bus ctrl., timeout
[51]
MCO controlled
[97]
Reference after ramp
N O T I C E
This option is only available with software version 48.XX.
Actual speed reference after the ramp. Use this output as master signal for speed synchroni-
zation of follower drives. The reference is set in parameter 16-48 Speed Ref. After Ramp [RPM].
[99]
Virtual master speed
N O T I C E
This option is only available with software version 48.XX.
Virtual master signal for controlling the speed or position of the followers.
[100]
Output frequency
[101]
Reference
[102]
Feedback
[103]
Motor current
[104]
Torque rel to limit
[105]
Torque related to rated
[106]
Power
[107]
Speed
[108]
Torque
[109]
Max out freq
[119]
Torque % lim
Parameter 5-65 Pulse Output Max Freq #29
Table 378: Parameter 5-65 Pulse Output Max Freq #29
5-65 Pulse Output Max Freq #29
Default value: Size related
Parameter type: Range, 0 - 110000 Hz
Setup: All setups
Conversion index: 0
Data type: Uint32
Change during operation: True
AU275636650261en-000101 / 130R0334 | 223Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
