FC 300 Design Guide
How to Program
Digital input DI29 [36]
Digital input DI32 [37]
Digital input DI33 [38]
Start command [39]
Drive stopped [40]
Function:
The list describes the available Boolean (TRUE or
FALSE) input for use in the se lected logic rule .
• *False [0] (default setting) - enters the fixed
value of FALSE in the logic rule.
• True [1] - enters the fixed value TRUE
in the log ic rule.
• Running [2] - see p ar. 5-13 for further
description.
• In range [3] - see par. 5-31 for further
description.
• On reference [4] - see par. 5 -31 for
further description.
• Torque limit [5] - see par. 5-31 for
further description.
• Current limit [6] - see par. 5-31 for
further description.
• Out of current range [ 7] - see par. 5-31
for further description.
• Below I low [8] - see pa r. 5-31 for
further description.
• Above I high [9] - see par. 5-31 for
further description.
• Below frequency low [11] - see par. 5-31
for further description.
• Above frequency high [12] - see par. 5-31
for further description.
• Thermal warning [16] - see par. 5-31
for further description.
• Mains out of range [17] - see par. 5-31
for further description.
• Reve rse [18] - see par. 5-31 for further
description.
• Warning [19] - see par. 5-31 for further
description.
• Alarm(trip)[20]-seepar. 5-31for
further description.
• Alarm (trip lock) [21] - see par. 5-31
for further description.
• Comparator 0 [22] - use the result of
comparator 0 in the logic rule.
• Comparator 1 [23] - use the result of
comparator 1 in the logic rule.
• Comparator 2 [24] - use the result of
comparator 2 in the logic rule.
• Comparator 3 [25] - use the result of
comparator 3 in the logic rule.
• Logicrule0[26]-usetheresultoflogic
rule 0 in the logic rule .
• Logicrule1[27]-usetheresultoflogic
rule 1 in the logic rule .
• Logicrule2[28]-usetheresultoflogic
rule 2 in the logic rule .
• Logicrule3[29]-usetheresultoflogic
rule 3 in the logic rule .
• Digital input DI18 [33] - use the value of DI18
in the logic rule (High = TRUE).
• Digital input DI19 [34] - use the value of DI19
in the logic rule (High = TRUE).
• Digital input DI27 [35] - use the value of DI27
in the logic rule (High = TRUE).
• Digital input DI29 [36] - use the value of DI29
in the logic rule (High = TRUE).
• Digital input DI32 [37] - use the value of DI32
in the logic rule (High = TRUE).
• Digital input DI33 [38] - use the value of DI33
in the logic rule (High = TRUE).
13-02 Stop Event
Option:
FALSE [0]
TRUE [1]
Running [2]
In range [3]
On reference [4]
Torq ue l imi t [5 ]
Current limit [6]
Out of current range [7]
Below I low [8]
Above I high [9]
Below speed low [11]
Above speed high [12]
Out of feedb. range [13]
Below feedb. low [14]
Above feedb. high [15]
Thermal warning [16]
Mains out of range [17]
Reverse [18]
Warning [19]
Alarm (trip) [20]
Alarm (trip lock) [21 ]
Comparator 0 [22]
*
default setting ()display text []value for use in communication via serial communication port
196
MG.33.B
3.22 - VLT is a registered Danfoss trademark
