FC 300 Design Guide
How to Program
Comparator 1 [23]
Comparator 2 [24]
Comparator 3 [25]
Logic rule 0 [26]
Logic rule 1 [27]
Logic rule 2 [28]
Logic rule 3 [29]
SL Timeout 0 [30]
SL Timeout 1 [31]
SL Timeout 2 [32]
Digital input DI18 [33]
Digital input DI19 [34]
Digital input DI27 [35]
Digital input DI29 [36]
Digital input DI32 [37]
Digital input DI33 [38]
Start command [39]
Drive stopped [40]
Function:
The list describ es which Boole an input is to define
to stop/deactivate the Smart Logic Control.
• *False [0] (default setting) - enters the fixed
value of FALSE in the logic rule.
• True [1] - enters the fixed value TRUE
in the log ic rule.
• Running [2] - see p ar. 5-13 for further
description.
• In range [3] - see par. 5-31 for further
description.
• On reference [4] - see par. 5 -31 for
further description.
• Torque limit [5] - see par. 5-31 for
further description.
• Current limit [6] - see par. 5-31 for
further description.
• Out of current range [ 7] - see par. 5-31
for further description.
• Below I low [8] - see pa r. 5-31 for
further description.
• Above I high [9] - see par. 5-31 for
further description.
• Below frequency low [11] - see par. 5-31
for further description.
• Above frequency high [12] - see par. 5-
31
for further description.
• Thermal warning [16] - see par. 5-31
for further description.
• Mains out of range [17] - see par. 5-31
for further description.
• Reverse [18] - see pa r. 5-31 for further
description.
• Warning [19] - see par. 5-31 for further
description.
• Alarm(trip)[20]-seepar. 5-31for
further description.
• Alarm(triplock)[21]-seepar. 5-31
for further description.
• Comparator 0 [22] - use the result of
comparator 0 in the logic rule.
• Comparator 1 [23] - use the result of
comparator 1 in the logic rule.
• Comparator 2 [24] - use the result of
comparator 2 in the logic rule.
• Comparator 3 [25] - use the result of
comparator 3 in the logic rule.
• Logicrule0[26]-usetheresultoflogic
rule 0 in the logic rule .
• Logicrule1[27]-usetheresultoflogic
rule 1 in the logic rule .
• Logicrule2[28]-usetheresultoflogic
rule 2 in the logic rule .
• Logicrule3[29]-usetheresultoflogic
rule 3 in the logic rule .
• Digital input DI18 [33] - use the value of DI18
in the logic rule (High = TRUE).
• Digital input DI19 [34] - use the value of DI19
in the logic rule (High = TRUE).
• Digital input DI27 [35] - use the value of DI27
in the logic rule (High = TRUE).
• Digital input DI29 [36] - use the value of DI29
in the logic rule (High = TRUE).
• Digital input DI32 [37] - use the value of DI32
in the logic rule (High = TRUE).
• Digital input DI33 [38] - use the value of DI33
in the logic rule (High = TRUE).
13-03 Reset SLC
Option:
*
Do not reset SLC [0]
Reset SLC [1]
Function:
Par. 13-03resetsallgroup13parameters
(13-*) to default settings.
" 13-1* Comparators
Used for comparing continuous variables (i.e. output
frequency, output current, analog input etc.) with
a fixed preset value. Comparators are evalu
ated
once in each scan interval. You can use the result
*
default setting ()display text []value for use in communication via serial communication port
197
MG.33.B
3.22 - VLT is a registered Danfoss trademark
