FC 300 Design Guide
How to Program
• On reference [4] - see par. 5 -31 for
further description.
• Torque limit [5] - see par. 5-31 for
further description.
• Current limit [6] - see par. 5-31 for
further description.
• Out of current range [ 7] - see par. 5-31
for further description.
• Below I low [8] - see pa r. 5-31 for
further description.
• Above I high [9] - see par. 5-31 for
further description.
• Below frequency low [11] - see par. 5-31
for further description.
• Above frequency high [12] - see par. 5-31
for further description.
• Thermal warning [16] - see par. 5-31
for further description.
• Mains voltage out of range [17] - see pa r.
5-31 for further description.
• Reversing [18 ] - see par. 5-31 for
further description.
• Warning [19] - see par. 5-31 for further
description.
• Alarm(trip)[20]-seepar. 5-31for
further description.
• Alarm (trip lock) [21] - see par. 5-31
for further description.
• Comparator 0 [22] - use the result of
comparator 0 in the logic rule.
• Comparator 1 [23] - use the result of
comparator 1 in the logic rule.
• Comparator 2 [24] - use the result of
comparator 2 in the logic rule.
• Comparator 3 [25] - use the result of
comparator 3 in the logic rule.
• Logicrule0[26]-usetheresultoflogic
rule 0 in the logic rule.
• Logicrule1[27]-usetheresultoflogic
rule 1 in the logic rule.
• Logicrule2[28]-usetheresultoflogic
rule 2 in the logic rule.
• Logicrule3[29]-usetheresultoflogic
rule 3 in the logic rule.
• Time-out0[30]-usetheresultoftimer
0 in the logic rule.
• Time-out1[31]-usetheresultoftimer
1 in the logic rule.
• Time-out2[32]-usetheresultoftimer
2 in the logic rule.
• Digital input DI18 [33] - use the value of DI18
in the logic rule (High = TRUE).
• Digital input DI19 [34] - use the value of DI19
in the logic rule (High = TRUE).
• Digital input DI27 [35] - use the value of DI27
in the logic rule (High = TRUE).
• Digital input DI29 [36] - use the value of DI29
in the logic rule (High = TRUE).
• Digital input DI32 [37] - use the value of DI32
in the logic rule (High = TRUE).
• Digital input DI33 [38] - use the value of DI33
in the logic rule (High = TRUE).
13-41 Logic Rule Operator 1
Array [4]
Option:
*
Disabled [0]
And [1]
Or [2]
And not [3]
Or not [4]
Not and [5]
Not or [6]
Not and not [7]
Not or not [8]
Function:
Selects the logical operator to use on the Boolean
inputs from par. 13-40 and 13-42.
[13 -XX] signifies the Boolean input of par. 13-*.
• DISABLED [0] - select this option to ignore
par. 13-42, 13-43 , and 13-44 .
• AND[1]-evaluatestheexpression
[13-40] AND [13-42].
• OR[2]-evaluatestheexpression
[13-40] OR [13-42].
• ANDNOT[3]-evaluatestheexpression
[13-40] AND NOT [13-42].
• OR NOT [4] - evaluates the expre ssion
[13-40] OR NOT [ 13-42].
• NOT AND [5] - evaluates the expression
NOT [13-40] AND [13-42].
• NOT OR [6] - evaluates the expression
NOT [13-40] OR [13-42].
• NOT AND NOT [7] - evaluates the expression
NOT [13-40] AND NOT [13-42].
• NOTORNOT[8]-evaluatestheexpression
NOT [13-40] OR NOT [13-42].
*
default setting ()display text []value for use in communication via serial communication port
200
MG.33.B
3.22 - VLT is a registered Danfoss trademark
