13-42 Logic Ru le Boolean 2
Array [4]
Option:
*False [0]
True [1]
Running [2]
In range [3]
On reference [4]
To rque lim it [5]
Current limit [6]
Out of current range [7]
Below I low [8]
Above I high [9]
Below speed low [11]
Above speed high [12]
Thermal warning [16]
Mains voltage out of range [17]
Reversing [18]
Warning [19]
Alarm (trip) [20]
Alarm (trip lo ck) [21]
Comparator 0 [22]
Comparator 1 [23]
Comparator 2 [24]
Comparator 3 [25]
Logic rule 0 [26]
Logic rule 1 [27]
Logic rule 2 [28]
Logic rule 3 [29]
Time-out 0 [30]
Time-out 1 [31]
Time-out 2 [32]
Digital input DI18 [33]
Digital input DI19 [34]
Digital input DI27 [35]
Digital input DI29 [36]
Digital input DI32 [37]
Digital input DI33 [38]
Function:
Same as in par. 13-40.
13-43 Logic R ule Operator 2
Array [4]
Option:
*
Disabled [0]
And [1]
Or [2]
And not [3]
Or not [4]
Not and [5]
Not or [6]
Not and not [7]
Not or not [8]
Function:
Selects the logical to be use on the Boolean input
calculated in par. 13 -40, 13-41, and 13-42, a nd
the Boolean input coming from par. 13-42.
• [13-44] signifies the Boolean input of par. 13-44.
• [13-40/13-42] signifies the Boolean input
calculated in par. 13-40, 13-41, and 13-42.
• DISABLED [0] (factory setting) - select this
option to i gnore par. 13-44.
• AND [1]-evaluatestheexpression
[13-40/13-42] AND [13-44].
• OR [2]-evaluatestheexpression
[13-40/13-42] OR [13-44].
• AND NOT [3]-evaluatestheexpression
[13-40/13-42] AND NOT [13-44].
• OR N OT [4]-evaluatestheexpression
[13-40/13-42] OR NOT [13-44].
• NOT A ND [5] - evaluates the expression NOT
[13-40/13-42] AND [13-44].
• NOT OR [6]-evaluatestheexpressionNOT
[13-40/13-42] OR [13-44].
• NOT AN D NOT [7 ] - evaluates the exp ression
NOT [13-40/13-4 2].
• evaluates AND NOT [13-44].
• NOT OR NOT [8]-evaluatestheexpression
NOT [13-40/13-42] OR NOT [13-44].
13-44 Logic Rule Boolean 3
Array [4]
Option:
*
False [0]
True [1]
Running [2]
In range [3]
On reference [4]
Torq ue l imi t [5 ]
Current limit [6]
Out of current range [7]
*
default setting ()display text []value for use in communication via serial communication port
201
MG.33.B
3.22 - VLT is a registered Danfoss trademark
