3.2.3.3
Relays and Terminals on Enclosure Sizes H3–H5
e30bb634.10
1
2
2
3
4
M
ot
or
U
V
W
-DC
+DC
M
AINS
1
Mains
3
Compressor
2
Ground
4
Relays
Illustration
7:
Enclosure Sizes H3–H5, IP20, 200–240 V, 6.0–10 kW (8.0–15 hp), IP20, 380–480 V, 6.0–22 kW (8.0–30 hp)
Installation
Operating Guide
| VLT® Compressor Drive CDS 803
AQ321748767627en-000101 / 130R0570| 17
Danfoss A/S © 2019.12
16
18
