Danfoss VLT FC 300 Operating Instructions

3
5
U/T1 96
FASTENER TORQUE: M10 19 Nm (14 FT-LB)
V/T2 97 W/T3 98 U/T1 96
FASTENER TORQUE: M10 19 Nm (14 FT-LB)
V/T2 97 W/T3 98 U/T1 96
FASTENER TORQUE: M10 19 Nm (14 FT-LB)
V/T2 97 W/T3 98
6
4, 8, 9
2
1
7
130BA862.12
Illustration 3.27 Inverter Cabinet, frame size F12 and F13
1)
External Temperature Monitoring 6) Motor
2) AUX Relay U V W
01 02 03 96 97 98
04 05 06 T1 T2 T3
3) NAMUR 7)
NAMUR Fuse. See 3.3.13 Fuses for part numbers
4) AUX Fan 8)
Fan Fuses. See 3.3.13 Fuses for part numbers
100 101 102 103 9)
SMPS Fuses. See 3.3.13 Fuses for part numbers
L1 L2 L1 L2
5) Brake
-R +R
81 82
How to Install
VLT
®
Automation Drive FC 300 12-Pulse
Operating Instructions High Power
34 MG34Q202 - VLT
®
is a registered Danfoss trademark
