VLT
®
FCD Series
The below explanations refer to the ordering form.
P
ower sizes (positions 1-6):
0,37 kW – 3,3 kW (See power size selection table)
A
pplication range (position 7):
• P-process
M
ains voltage (positions 8-9):
• T4 - 380-480 V three phase supply voltage
E
nclosure (positions 10-12):
The enclosure offers protection against dusty,
wet, and aggressive environment
• P66 - Protected IP66 enclosure (exceptions
see Installation box T00, T73)
H
ardware variant (positions 13-14):
• ST - Standard hardware
• EX - 24 V external supply for backup of control card
• EB - 24 V external supply for backup of control
card, control and supply of mechanical brake
and an additional brake chopper
R
FI filter (positions 15-16):
• R1 - Compliance with class A1 filter
D
isplay unit (LCP) (positions 17-18):
Connection possibility for display and keypad
• D0 - No pluggable display connector in the unit
• DC - Display connector plug mounted (not available
with "only right side" installation box variants)
F
ieldbus option card (positions 19-21):
A wide selection of high performance fieldbus
options is available (integrated)
• F00 - No fieldbus option built in
• F10 - Profibus DP V0/V1 3 Mbaud
• F12-ProfibusDPV0/V112Mbaud
• F30 - DeviceNet
• F70 - AS-interface
I
nstallation box (positions 22-24):
• T00 - No Installation box
• T11 - Installation box, motor mount, metric
thread, only right side
• T12 - Installation box, motor mount, metric
thread, double side
• T16 - Installation box, motor mount, NPT
thread, double side
• T22 - Installation box, motor mount, metric
thread, double side, service switch
• T26 - Installation box, motor mount, NPT
thread, double side, service switch
• T51 - Installation box, wall mount, metric
thread, only right side
• T52 - Installation box, wall mount, metric
thread, double side
• T56 - Installation box, wall mount, NPT
thread, double side
• T62 - Installation box, wall mount, metric
thread, double side, service switch
• T66 - Installation box, wall mount, NPT thread,
double side, service switch
• T63 - Installation box, wall mount, metric thread,
double side, service switch, sensor plugs
• T73 - Installation box, wall mount, metric thread,
double side, motor plug, sensor plugs, Viton gasket
C
oating (positions 25-26):
The IP66 enclosure offers protection of the drive
against aggressive environments, which practically
eliminates the need for coated printed circuit boards.
• C0 - Non coated boards
MG.04.B7.02 - VLT is a registered Danfoss trademark
114
