VLT
®
FCD Series
Coiled wire brake resistors Duty-cycle 40%
Type
P
motor
[kW]
R
MIN
[
]
R
REC
[
]
P
peak
[kW]
P
avg.
[kW]
Order no.
175U0xxx
303 (400 V) 0.37 747 830 0.60 0.25 976
305 (400 V)
0.55 747 830 0.60 0.25 976
307 (400 V) 0.75 558 620 0.90 0.36 910
311 (400 V) 1.10 387 430 1.32 0.53 911
315 (400 V) 1.50 297 330 1.80 0.72 912
322 (400 V) 2.20 198 220 2.60 1.06 913
330 (400 V) 3.00 135 150 3.60 1.44 914
R
REC
= Recommended brake resistor.
P
peak
= Max. brake effect at 160% brake torque.
P
avg
= Mean power based on Duty-cycle.
See dimensions of Coiled wire brake resistors in in-
structions MI.50.D2.XX.
MG.04.A1.02 - VLT is a registered Danfoss trade mark
