Danfoss VLT HVAC Drive FC 102 - Page 160

2
3
4
5
6
7
8
1
130BF864.10
1 Balance/high frequency card 5 Midplate
2 Insulator sheet 1 6 DC(+) plate
3 DC(-) plate 7 Capacitor locking panel
4 Insulator sheet 2 8 Standard DC capacitor
Illustration 10.13 Standard DC Capacitor Bank, 240/400 V AC Unit
D1h/D3h/D5h/D6h/J8 Drive Di...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
158 Danfoss A/S © 02/2019 All rights reserved. MG94A502
