1
2
3
5
4
6
7
8
e30bg565.10
1 Thread-forming screw (T20) 5 Power terminal mounting plate
2 Current sensor 6 Mounting hole
3 Current sensor cable connector 7 Wire guide
4 Mounting hole 8 Cable clip
Illustration 11.6 D2h Power Terminal Mounting Plate and Current Sensors
D2h/D4h/D7h/D8h/J9 Unit Dis...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
202 Danfoss A/S © 02/2019 All rights reserved. MG94A502
1111
