Danfoss VLT HVAC Drive FC 102 - Page 235

4
e30bg420.10
5
2
1
3
6
1 Screwdriver access holes for captive screws (T25) 4 Nut (T25)
2 Threaded stud 5 Telescoping duct
3 Duct ange 6 Heat sink fan cover
Illustration 11.31 Heat Sink Fan Access with Telescoping Cooling Duct
D2h/D4h/D7h/D8h/J9 Unit Dis... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 233
11 11
