21-55 Ext. 3 Setpoint
Range: Function:
0 ExtPID3Unit* [ par. 21-51 - par.
21-52 ExtPID3Unit]
See parameter 21-15 Ext. 1
Setpoint for details.
21-57 Ext. 3 Reference [Unit]
Range: Function:
0 ExtPID3Unit* [-999999.999 -
999999.999
ExtPID3Unit]
See parameter 21-17 Ext. 1
Reference [Unit] for details.
21-58 Ext. 3 Feedback [Unit]
Range: Function:
0 ExtPID3Unit* [-999999.999 -
999999.999
ExtPID3Unit]
See parameter 21-18 Ext. 1
Feedback [Unit] for details.
21-59 Ext. 3 Output [%]
Range: Function:
0 %* [0 - 100 %]
See parameter 21-19 Ext. 1 Output [%] for
details.
3.19.7 21-6* Closed Loop 3 PID
21-60 Ext. 3 Normal/Inverse Control
Option: Function:
See parameter 21-20 Ext. 1 Normal/Inverse Control
for details.
[0] * Normal
[1] Inverse
21-61 Ext. 3 Proportional Gain
Range: Function:
0.01* [0 - 10 ]
See parameter 21-21 Ext. 1 Proportional Gain for
details.
21-62 Ext. 3 Integral Time
Range: Function:
10000 s* [0.01 - 10000 s]
See parameter 21-22 Ext. 1 Integral
Time for details.
21-63 Ext. 3 Dierentation Time
Range: Function:
0 s* [0 - 10 s]
See parameter 21-23 Ext. 1 Dierentation Time for
details.
21-64 Ext. 3 Dif. Gain Limit
Range: Function:
5* [1 - 50 ]
See parameter 21-24 Ext. 1 Dif. Gain Limit for
details.
