5.1.11 10-** CAN Fieldbus
Param
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
10-0* Common Settings
10-00 CAN Protocol ExpressionLimit 2 set-ups FALSE - Uint8
10-01 Baud Rate Select ExpressionLimit 2 set-ups TRUE - Uint8
10-02 MAC ID ExpressionLimit 2 set-ups TRUE 0 Uint8
10-05 Readout Transmit Error Counter 0 N/A All set-ups TRUE 0 Uint8
10-06 Readout Receive Error Counter 0 N/A All set-ups TRUE 0 Uint8
10-07 Readout Bus O Counter 0 N/A All set-ups TRUE 0 Uint8
10-1* DeviceNet
10-10 Process Data Type Selection ExpressionLimit All set-ups TRUE - Uint8
10-11 Process Data Cong Write ExpressionLimit 2 set-ups TRUE - Uint16
10-12 Process Data Cong Read ExpressionLimit 2 set-ups TRUE - Uint16
10-13 Warning Parameter 0 N/A All set-ups TRUE 0 Uint16
10-14 Net Reference [0] O 2 set-ups TRUE - Uint8
10-15 Net Control [0] O 2 set-ups TRUE - Uint8
10-2* COS Filters
10-20 COS Filter 1 0 N/A All set-ups FALSE 0 Uint16
10-21 COS Filter 2 0 N/A All set-ups FALSE 0 Uint16
10-22 COS Filter 3 0 N/A All set-ups FALSE 0 Uint16
10-23 COS Filter 4 0 N/A All set-ups FALSE 0 Uint16
10-3* Parameter Access
10-30 Array Index 0 N/A 2 set-ups TRUE 0 Uint8
10-31 Store Data Values [0] O All set-ups TRUE - Uint8
10-32 Devicenet Revision 0 N/A All set-ups TRUE 0 Uint16
10-33 Store Always [0] O 1 set-up TRUE - Uint8
