3.4.7 Installation of IP00 to IP20 Kits
The kits can be installed on enclosure size E2 adjustable
frequency drives (IP00).
CAUTION
See the instruction for Installation of IP20 Kits, 175R1108,
for further information.
Ordering information
•
Enclosure size E2: 176F1884
3.4.8
Installation of IP00 E2 Cable Clamp
Bracket
The motor cable clamp brackets can be installed on
enclosure types E2 (IP00).
NOTICE!
See the instruction for Cable Clamp Bracket Kit, 175R1109,
for further information.
Ordering information
•
Enclosure size E2: 176F1745
3.4.9
Installation of Line Power Shield for
Adjustable Frequency Drives
This section describes the installation of a line power
shield for the adjustable frequency drive series with
enclosure size E1. It is not possible to install in the IP00/
Chassis versions as they have included a metal cover as
standard. These shields meet VBG-4 requirements.
Ordering information:
•
Enclosure size E1: 176F1851
3.4.10
Enclosure Size F USB Extension Kit
A USB extension cable can be installed into the door of F-
frame adjustable frequency drives.
Ordering information:
•
176F1784
NOTICE!
For further information, see the Instruction Sheet,
177R0091.
