21-58 Ext. 3 Feedback [Unit]
Range: Function:
0.000 Ex-
tPID3Unit*
[-999999.999 - 999999.999 Ex-
tPID3Unit]
See par.21-18
Ext. 1 Feedback [Unit]
for details.
21-59 Ext. 3 Output [%]
Range: Function:
0 %* [0 - 100 %] See par.21-19
Ext. 1 Output [%]
for details.
3.19.8 21-6* Closed-loop 3 PID
Configure the closed-loop 3 PID controller.
21-60 Ext. 3 Normal/Inverse Control
Option: Function:
See par.21-20
Ext. 1 Normal/Inverse Control
for details.
[0] * Normal
[1] Inverse
21-61 Ext. 3 Proportional Gain
Range: Function:
0.01 N/A* [0.00 - 10.00 N/A] See par.21-21
Ext. 1 Proportional Gain
for details.
21-62 Ext. 3 Integral Time
Range: Function:
10000.00
s*
[0.01 - 10000.00 s] See par.21-22
Ext. 1 Integral Time
for details.
21-63 Ext. 3 Differentation Time
Range: Function:
0.00 s* [0.00 - 10.00 s] See par.21-23
Ext. 1 Differentation Time
for details.
21-64 Ext. 3 Dif. Gain Limit
Range: Function:
5.0 N/A* [1.0 - 50.0 N/A] See par.21-24
Ext. 1 Dif. Gain Limit
for details.
VLT
®
HVAC Drive Programming Guide 3 Parameter Description
MG.11.C6.22 - VLT
®
is a registered Danfoss trademark
3-195
3
