3.15.8 15-9* Parameter Info
Parameter lists
15-92 Defined Parameters
Array [1000]
Range: Function:
0 N/A* [0 - 9999 N/A] View a list of all defined parameters in the adjustable frequency drive. The list ends with 0.
15-93 Modified Parameters
Array [1000]
Range: Function:
0 N/A* [0 - 9999 N/A] View a list of the parameters that have been changed from their default setting. The list ends with
0. Changes may not be visible until up to 30 seconds after implementation.
15-99 Parameter Metadata
Array [23]
Range: Function:
0 N/A* [0 - 9999 N/A] This parameter contains data used by the MCT10 software tool.
3.16 Main Menu - Data Readouts - Group 16
3.16.1 16-** Data Readouts
Parameter group for data readouts, such as current references, voltages, control, alarm, warning and status words.
3.16.2 16-0* General Status
Parameters for reading the general status, such as the calculated reference, the active control word and status.
16-00 Control Word
Range: Function:
0 N/A* [0 - 65535 N/A] View the control word sent from the adjustable frequency drive via the serial communication port
in hex code.
16-01 Reference [Unit]
Range: Function:
0.000 Ref-
erenceFeed-
backUnit*
[-999999.000 - 999999.000 Refer-
enceFeedbackUnit]
View the present reference value applied on impulse or analog basis in the unit resulting from the
configuration selected in par.1-00
Configuration Mode
(Hz, Nm or RPM).
16-02 Reference %
Range: Function:
0.0 %* [-200.0 - 200.0 %]
16-03 Status Word
Range: Function:
0 N/A* [0 - 65535 N/A] View the status word sent from the adjustable frequency drive via the serial communication port in
hex code.
VLT
®
HVAC Drive Programming Guide 3 Parameter Description
MG.11.C6.22 - VLT
®
is a registered Danfoss trademark
3-151
