Page #33 background image
[1667] Pulse Input #29 [Hz]
[1668] Pulse Input #33 [Hz]
[1669] Pulse Output #27 [Hz] Actual value of pulses applied to terminal 27 in digital output mode.
[1670] Pulse Output #29 [Hz] Actual value of pulses applied to terminal 29 in digital output mode.
[1671] Relay Output [bin] View the setting of all relays.
[1672] Counter A View the present value of Counter A.
[1673] Counter B View the present value of Counter B.
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1680] Fieldbus CTW 1 Control word (CTW) received from the bus master.
[1682] Fieldbus REF 1 Main reference value sent with control word via the serial communications network, e.g., from the
BMS, PLC or other master controller.
[1684] Comm. Option Status Extended serial communication bus option status word.
[1685] FC Port CTW 1 Control word (CTW) received from the bus master.
[1686] FC Port REF 1 Status word (STW) sent to the bus master.
[1690] Alarm Word One or more alarms in a Hex code (used for serial communications)
[1691] Alarm word 2 One or more alarms in a Hex code (used for serial communications)
[1692] Warning Word One or more warnings in a Hex code (used for serial communications)
[1693] Warning word 2 One or more warnings in a Hex code (used for serial communications)
[1694] Ext. Status Word One or more status conditions in a Hex code (used for serial communications)
[1695] Ext. Status Word 2 One or more status conditions in a Hex code (used for serial communications)
[1696] Maintenance Word The bits reflect the status for the programmed preventive maintenance events in parameter group
23-1*
[1830] Analog Input X42/1 Shows the value of the signal applied to terminal X42/1 on the Analog I/O card.
[1831] Analog Input X42/3 Shows the value of the signal applied to terminal X42/3 on the Analog I/O card.
[1832] Analog Input X42/5 Shows the value of the signal applied to terminal X42/5 on the Analog I/O card.
[1833] Analog Out X42/7 [V] Shows the value of the signal applied to terminal X42/7 on the Analog I/O card.
[1834] Analog Out X42/9 [V] Shows the value of the signal applied to terminal X42/9 on the Analog I/O card.
[1835] Analog Out X42/11 [V] Shows the value of the signal applied to terminal X42/11 on the Analog I/O card.
[2117] Ext. 1 Reference [Unit] The value of the reference for extended Closed-loop Controller 1
[2118] Ext. 1 Feedback [Unit] The value of the feedback signal for extended Closed-loop Controller 1
[2119] Ext. 1 Output [%] The value of the output from extended Closed-loop Controller 1
[2137] Ext. 2 Reference [Unit] The value of the reference for extended Closed-loop Controller 2
[2138] Ext. 2 Feedback [Unit] The value of the feedback signal for extended Closed-loop Controller 2
[2139] Ext. 2 Output [%] The value of the output from extended Closed-loop Controller 2
[2157] Ext. 3 Reference [Unit] The value of the reference for extended Closed-loop Controller 3
VLT
®
HVAC Drive Programming Guide 3 Parameter Description
MG.11.C6.22 - VLT
®
is a registered Danfoss trademark
3-9
