Page #92 background imageLoading...
Page #92 background image
[167] Start cmd. active
[168] Hand mode
[169] Auto mode
[180] Clock Fault
[181] Prev. Maintenance
[190] No-Flow
[191] Dry Pump
[192] End Of Curve
[193] Sleep Mode
[194] Broken Belt
[195] Bypass Valve Control
[196] Fire Mode Active
[197] Fire Mode Was Active
[198] Bypass Mode Active
[200] Full capacity
[201] Pump 1 running
[202] Pump 2 running
[203] Pump 3 running
5-32 Term X30/6 Digi Out (MCB 101)
Option: Function:
[0] * No operation This parameter is active when option module MCB 101 is mounted in the adjustable frequency drive.
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Stand-by / no warning
[5] Running
[6] Running / no warning
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
[18] Out of feedb. range
[19] Below feedback, low
[20] Above feedback, high
[21] Thermal warning
[25] Reverse
[26] Bus OK
3 Parameter Description VLT
®
HVAC Drive Programming Guide
3-68
MG.11.C6.22 - VLT
®
is a registered Danfoss trademark
