Page #94 background imageLoading...
Page #94 background image
[194] Broken Belt
[195] Bypass Valve Control
[196] Fire Mode Active
[197] Fire Mode Was Active
[198] Bypass Mode Active
[200] Full capacity
[201] Pump 1 running
[202] Pump 2 running
[203] Pump 3 running
5-33 Term X30/7 Digi Out (MCB 101)
Option: Function:
[0] * No operation This parameter is active when option module MCB 101 is mounted in the adjustable frequency drive.
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Stand-by / no warning
[5] Running
[6] Running / no warning
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
[18] Out of feedb. range
[19] Below feedback, low
[20] Above feedback, high
[21] Thermal warning
[25] Reverse
[26] Bus OK
[27] Torque limit stop
[28] Brake: No Brake War
[29] Brake ready, no fault
[30] Brake fault (IGBT)
[35] External Interlock
[40] Out of ref range
[41] Below reference, low
[42] Above ref, high
[45] Bus ctrl.
3 Parameter Description VLT
®
HVAC Drive Programming Guide
3-70
MG.11.C6.22 - VLT
®
is a registered Danfoss trademark
3
